ABB - PROCESS PERFORMANCE MOTORS
Process performance motors are tough, high quality products designed for durability in the most demanding environments and applications. They are ideally suited to process industries and heavy duty applications – sectors like mining, cement and paper - where motors have to meet high requirements for reliability, availability and efficiency in harsh conditions.
Process performance motors provide great flexibility for customer specific solutions and can be individually designed to meet the exact demands of the application. There is a wide range of options for process industry applications available, as well as selected accessories including vibration and speed monitoring solutions. In addition the motors can be modified – including foot and flange adaptations – to ensure a good utilization level of motors kept in stock.
Specifications
| Power Range: | 0.37 Kw to 375 Kw |
| Frame Size: | 71 – 355 |
| Voltage Range: | 200 – 575V |
| Frequency Ranges: | 50 Hz & 60 Hz |
| Nos of Poles: | 2 / 4 / 6 / 8 |
| Efficiency Class : | IE2 /IE3 |
| Application: | Centrifugal pumps, Conveyors, Compressors, Crushers, Agitators, Reciprocating pumps, Punch presses, Mixture, Refiners, Gas compressor stations and Gas liquefaction plants. |
| Power Range: | 0.55 Kw to 560 Kw |
| Frame Size: | 280 – 355 |
| Voltage Range: | 200 – 575V |
| Frequency Range: | 50 Hz & 60 Hz |
| Nos of Poles: | 2 / 4 / 6 / 8 |
| Efficiency Class : | IE2 /IE3 |
| Application: | Centrifugal pumps, Conveyors, Compressors, Crushers, Agitators, Reciprocating pumps, Punch presses, Mixture, Refiners, Gas compressor stations and Gas liquefaction plants. |
| Power Range: | 0.25 Kw to 40 Kw |
| Frame Size: | 71 – 200 |
| Voltage Range: | 200 – 575V |
| Frequency Range: | 50 Hz & 60 Hz |
| Nos of Poles: | 2 / 4 / 6 / 8 |
| Efficiency Class : | IE2 /IE3 |
| Application: | Centrifugal pumps, Conveyors, Compressors, Crushers, Agitators, Reciprocating pumps, Punch presses, Mixture, Refiners, Gas compressor stations and Gas liquefaction plants. |
| Power Range: | 0.18 Kw to 55 Kw |
| Frame Size: | 80 – 250 |
| Voltage Range: | 200 – 575V |
| Frequency Range: | 50 Hz & 60 Hz |
| Nos of Poles: | 2 / 4 / 6 / 8 |
| Efficiency Class : | IE2 /IE3 |
| Application: | Centrifugal pumps, Conveyors, Compressors, Crushers, Agitators, Reciprocating pumps, Punch presses, Mixture, Refiners, Gas compressor stations and Gas liquefaction plants. |
| Power Range: | 0.37 Kw to 55 Kw |
| Frame Size: | 71 – 250 |
| Voltage Range: | 200 – 575V |
| Frequency Range: | 50 Hz & 60 Hz |
| Nos of Poles: | 2 / 4 / 6 / 8 |
| Efficiency Class : | IE2 /IE3 |
| Application: | Centrifugal pumps, Conveyors, Compressors, Crushers, Agitators, Reciprocating pumps, Punch presses, Mixture, Refiners, Gas compressor stations and Gas liquefaction plants. |
| Power Range: | 1.1 Kw to 315 Kw |
| Frame Size: | 90 to 315 |
| Voltage Range: | 230 – 690V |
| Frequency Ranges: | 50 Hz & 60 Hz |
| Nos of Poles: | 4 |
| Efficiency Class : | IE3 /IE4/IE5 |
| Application: | Centrifugal pumps, Conveyors, Compressors, Crushers, Agitators,Reciprocating pumps, Punch presses, Mixture, Refiners, Gas compressor stations and Gas liquefaction plants. |
| Power Range: | 2.0 Kw to 2000 Kw |
| Frame Size: | 80 to 400 |
| Voltage Range: | 400 – 690V |
| Frequency Range: | 50 Hz & 60 Hz |
| Nos of Poles: | 4 |
| Efficiency Class : | IP23/IP55 ( Blower , Fan and Liquid Cooled) |
| Application: | Centrifugal pumps, Conveyors, Compressors, Crushers, Agitators, Reciprocating pumps, Punch presses, Mixture, Refiners, Gas compressor stations and Gas liquefaction plants. |
